ULTRA CRYOSTAT CIRCULATOR
The inner chamber of the temperature bath shall be made out of Stainless Steel and Outer shall be made out of Mild Steel duly powder coated surface.
The complete system shall be mounted on sturdy angle iron frame.
The refrigeration system consists of hermetically sealed compressor using CFC free gas, condenser, air cooled by a separate heavy duty motor driven fan and evaporator coil which brings down the temperature.
All the joints of the system are specially treated to prevent refrigeration loss.
The cooling of this system shall be evenly placed inside the inner chamber of the temperature bath.
High efficient Magnetic pump will be provided for external circulation.
Temperature will be controlled by Proportional digital indicating controller with PT 100 sensor.
Specifications:
Tank Capacity : 17.5 litres
Inner working chamber : 350L x 200 W x 250D mm
Clear Working Chamber : 250L x 200 W x 250D mm
Temperature range : – 30°C to Ambient
Temperature control : By means of PID controller with pt 100 sensors.
Control Accuracy : ± 0.1°C
Mains : 220-230 Volts AC single phase.
| Cat.No | Temperature Range | Flow LPM |
| RUCC-1 | 0°C to Ambient | 15 LPM |
| RUCC-2 | 0°C to 100°C | 15 LPM |
| RUCC-3 | -20°C to Ambient | 15 LPM |
| RUCC-4 | -20°C to 100°C | 15 LPM |
| RUCC-5 | -30°C to Ambient | 15 LPM |
| RUCC-6 | -30°C to 100°C | 15 LPM |
The above model is a standard model we supply; Custom built size with different temperature range can also be designed and supplied, as per customer requirement.
